PrimaluceLab ECCO Environmental Computerized Controller for EAGLE
ECCO2 is the Environmental Computerized COntroller for EAGLE that automates the management of dew heaters during long exposure astrophotography. By adding the ECCO module to your EAGLE, it will automatically and continuously monitor the temperature, humidity and pressure around your telescope and the temperature of your lenses by calculating the dew point (the temperature below which dew condenses). This way it will vary the heating of dew heaters connected to the dew heater ports of the EAGLE avoiding condensation on your optics. It is automatic with this easy to use device. Just connect it to the EAGLE's USB port. For this reason we decided to call it ECCO. In Italian, it means "There you go!” The second generation ECCO now comes with USB-C type port, added pressure sensor, SMART control of temperature probes and DARK mode. ECCO2 is also provided with an ASCOM driver to control it also with third party software, also from standard Windows 10/11 computers!
Plug&Play functionality
We decided to call it ECCO not only because it is the “Environmental Computerized COntroller” but also because it is very easy to use (in Italian, ECCO means "There you go"). In fact, just connect the temperature sensors (to be fixed near the optics of your telescope) and the USB cable to one of the EAGLE USB ports (ECCO is compatible with second generation EAGLE equipped with dew heaters power ports), and press CONNECT button in the EAGLE Manager (it needs EAGLE Manager at least version 2.0). You can see in real time the dew point calculation, the temperature detected by the temperature probes you have installed and the variation of the power supplied by the EAGLE to the dew heaters. ECCO does not require external power supply!
EAGLE Manager starting from version 2.0 supports ECCO with dew point calculation and automatic control of power of dew heaters
Very easy to install on your telescope
PrimaluceLab ECCO can be installed on any finder base like our DX base or Celestron, SkyWatcher or GSO telescopes. It is therefore very easy to connect to your telescope. If you do not have a standard finder base, you can install one of the many optional bases and then connect the ECCO. We designed ECCO as an external module of the EAGLE and not as an integrated instrument because, if it were internal to the EAGLE, its measurements of temperature and humidity of the air would be influenced by the (even if weak) heat created by the EAGLE during use. With an external module, the data recorded by ECCO is incredibly precise.
ECCO installed on AIRY refractor telescope, connected to the EAGLE with USB port and with 2 external temperature probes
ECCO installed on a Schmidt-Cassegrain telescope, connected to the EAGLE with USB port and with 2 external temperature probes
Great PrimaLuceLab design
As with all our products, ECCO offers you innovative features in a product characterized by refined design and high quality construction. Made entirely of 6061 T6 aluminum and produced using CNC machines, ECCO is completely red anodized to increase the strength and durability of the materials. It can also be used as a finder support by adding the optional "Finder support for ECCO". You can install your finder or guide scope above ECCO instead of using guide rings (this is a perfect solution, for example, for small apochromatic refractors and very portable setups).
ECCO used together with the "Guide scope support for ECCO" in order to use a guide scope or a finder.
Technical Specifications
ECCO2, environmental computerized controller for EAGLE - main features:
- Computerized controller to be installed on your telescope
- Plug&Play: just connect to the EAGLE and it works!
- USB Type C port with reversible plug: safe and reliable
- It adds automatic power control to dew heaters connected to the dew ports of the EAGLE
- Temperature, humidity and pressure sensors to automatically calculate dew point
- 3x ports for temperature probes
- DARK mode to disable the LED light
- SMART control of temperature probes to automatically detect uncalibrated or wrongly connected temperature probes
- ASCOM driver to control ECCO2 from external softwares or even standard Windows 10/11 computers
- It supports compact guide scopes when used with “Guide scope support for ECCO”
- Weight: 75 gr.
In the Box
PrimaluceLab ECCO2 Environmental Computerized Controller for EAGLE
Warranty & Manuals
PrimaluceLab 1-Year Warranty
