Planar APO Astronomical Telescope


The ToupTek HOPE D60 is designed as an excellent telescope for astrophotography while also being ideal for beginners who want to explore the universe with ease. Unlike bulky reflecting telescopes, this compact Planar APO refractor combines portability with a professional five-element optical system, minimizing chromatic aberration and delivering diffraction-limited clarity.
With its fast f/4.66 focal ratio and built-in field flattener, the HOPE D60 is a true astrograph, providing wide, flat images without the need for additional accessories. A dual-speed focuser and versatile threaded connections make setup easy for newcomers, while giving advanced users precise control for capturing galaxies, nebulae, and star fields.
The HOPE D60 combines beginner-friendly simplicity with professional performance, making it a telescope that grows with you throughout your astronomy journey.

1. Optical Design
2. Precise Mechanical Design
3. Compact and Robust OTA
4. Highly Compatible Interfaces
5. Compatible with Electric Focusers of Multiple Brands
6. Versatile Usage

The HOPE D60 astronomical telescope achieves a central RMS spot size <1.1 µm and the full-frame edge RMS <2.3 µm, delivering exceptionally fine, concentrated star points. Multi-wavelength focus remains consistent with near-zero chromatic aberration, ensuring sharp, accurate imaging across the field of view.
A spot diagram illustrates how light from a star is distributed on the telescope’s focal plane, visually confirming stellar precision.

MTF curve shows consistently high resolution and minimal S/T variation across the full frame.
HOPE D60 is a high-resolution telescope for viewing planets and galaxies, delivering accurate celestial detail reproduction with exceptional uniformity — achieving MTF >0.95 at 10 LP/mm and >0.85 at 30 LP/mm, with minimal Sagittal/Tangential variation across the frame.

Exceptional Chromatic Aberration Control.
The axial aberration curve is flat, with multi-wavelength light converging on the same plane. This ensures minimal spherical and chromatic aberration, delivering sharp, color-accurate imaging across the entire field of view.

Even Brightness, No Edge Vignetting
The HOPE D60 refractor telescope maintains >90% relative illumination at the 44mm full-frame edge, meaning brightness difference between center and edge is <10%. The curve decays smoothly, ensuring uniform brightness with no vignetting.
Relative illumination measures brightness uniformity across the image plane, showing how light falls from the center (0mm) to the full-frame edge (22mm).
| Specification | Value |
|---|---|
| Aperture | 60 mm |
| Focal Length | 280 mm |
| Focal Ratio | f/4.66 |
| Optical Design | 5-element apochromatic (PAPO) refractor with built-in field flattener |
| Image Circle / Sensor Coverage | Full-frame coverage (~44 mm image circle) |
| Relative Illumination at Edge | >90% at 44 mm image circle edge |
| Mechanical Mounting / Compatibility | Standard M48×0.75 thread; optional M54×0.75 adapter available |
| Focuser | 3-inch rack & pinion focuser with ~30 mm travel, coarse and fine adjustments, zero backlash |
| Compact Length | 255 mm (dew shield retracted) |
| Tube Material / Construction | CNC-machined aluminium alloy body with blackened interior and retractable dew shield |
| Back-Focus / Connection Distance | Recommended 55 mm (supports 50–58 mm) |
| Intended Use | Astrophotography, wide-field deep-sky imaging; not recommended for visual observation |
| Weight (Approx.) | 3.5 kg |
