Meticulous Mid-Range Machinery
Sky-Watcher SynScan mounts have been designed for use by novices and experts alike. These mounts provide extremely high precision tracking and have built in autoguider ports. This heavy-duty HEQ5 Pro mount is a smaller version of the sturdy EQ6 Pro mount. It is specially designed for observers who need the steadiness of the EQ6 Pro mount but find it too physically demanding. But make no mistake, the HEQ5 Pro can be that perfect mid-range rock solid platform you build your astroimaging rig on.
42,000+ Object Database
For novice users, the user-friendly menu allows automatic slewing to 42,900+ objects. Even an inexperienced astronomer can master its variety of features in a few observing sessions. The hand controller can be connected to a PC using the built-in USB-B port and a USB-B cable (not included). PC control can be done with SynScan Pro for Windows app or your favorite third-party software with the correct drivers.
Flexible Polar Alignment
Sky-Watcher includes an illuminated polar finderscope to aid the alignment process. The finderscope features a circular grid reticle for the Northern Hemisphere, consistent with today’s popular polar alignment apps. For astronomers in the Southern Hemisphere, the constellation Octans is built into the reticle as well. Even without a clear view of Polaris, the HEQ5 Pro can be polar aligned using our SynScan hand controller. Simply choose one of the visible stars listed and use the latitude adjustment screws to center it in the eyepiece.
Bundle of Accessories
As customary with all Sky-Watcher products, an assortment of accessories are included with the HEQ5 Pro mount. A retractable counterweight bar is supplied, allowing for easier transportation. Two 11-pound counterweights are also included to help balance up to a 30-pound payload. The HEQ5 Pro features a saddle compatible with both D- and V-style mounting plates, allowing users the flexibility to utilize multiple optical tubes, even if the mounting plate is different.
Additional Features:
- HEQ5 GoTo equatorial head
- 30-pound payload capacity
- Adjustable 1.75-inch diameter rolled steel tripod
- SynScan GoTo telescope mount with 42,900+ object database
- Built-in polar scope with illuminator
- Two 11-pound counterweights
- Metal accessory tray
- D/V-style dovetail saddle
- SynScan V5 hand controller
- DC power cord
Technical Specifications
| Tripod Height |
97-121cm |
| Guiding Speed |
from 0.25X, 0.50X, 0.75X, or 1X |
| Mount Type |
German Equatorial Mount |
| Counter Weight |
2 x 5.1Kgs |
| Accessory Tray |
Large wall-to-wall |
| Motor Drive |
1.8 degree stepper motors |
| GOTO System |
SynScan Hand Control |
| Tripod Weight |
5.6 kg, 1.75″ steel tripod |
| Shipping Weight |
18+12 kg |
| Shipping Dimensions |
127x24x25 cm3; 44x44x19 cm3 |
| Payload Capacity |
13.7 kg |
| Slewing Speed |
up to 3.4°/sec (800X) |
In the Box
- Sky-Watcher HEQ5 Mount
- Adjustable 1.75" Rolled Steel Tripod
- SynScan GoTo w/ 42,900+ object database
- Metal Tray Accessory
- Dual-Style Dovetail Saddle
- SynScan V5 Hand Controller
- 12V DC Power Cord with Cigarette Lighter Adapter
- Two 11 lb. Counterweights
- AC Adapter NOT INCLUDED, if you want one, here is the AC/DC power adapter
Warranty & Manuals
Sky-Watcher 2-Year Warranty
